All models share a 25.6V nominal LiFePO4 system, steel IP67 enclosure, built-in BMS (overcharge, over-discharge, temperature & short-circuit protection), and compatibility with standard 24V industrial forklift chargers.
| Parameter | UFO24105 | UFO24206 | UFO24210 | 24V 304Ah Series |
|---|---|---|---|---|
| Nominal Voltage | 25.6V | 25.6V | 25.6V | 25.6V |
| Rated Capacity | 105Ah | 206Ah | 210Ah | 304Ah |
| Energy | 2688Wh | 5273.6Wh | 5376Wh | 7780Wh |
| Dimensions (L×W×H) | 660×185×590mm | 550×210×380mm | 624×235×627mm | 624×284×627mm |
| Weight | ~24KG | 50KG | ~48KG | 66KG |
| Charge Voltage | 29.2V | 29.2V | 29.2V | 29.2V |
| Cut-off Voltage | 20V | 20V | 20V | 20V |
| Charge Current | 100A | 100A | 100A | 200A |
| Continuous Discharge | 200A | 200A | 200A | 230A |
| Peak Discharge | 400A | 400A | 400A | 460A (30s) |
| Cycle Life | >4000 cycles | >4000 cycles | >4000 cycles | >4000 cycles |
| Case Material & IP Rating | Steel, IP67 | Steel, IP67 | Steel, IP67 | Steel, IP67 |
| BMS | Built-in | Built-in | Built-in | Built-in |
Note: The above are standard lineup examples. UFOPOWER offers extensive custom engineering – voltage & capacity from 24V to 80V+ (up to 1000Ah+), physical dimensions to fit your equipment, communication protocols compatible with most BMS systems, special features (low-temp heating, GPS tracking, remote monitoring), and customized connector types.
Designed to keep your fleet moving with minimal downtime, the 24V series charges rapidly during breaks and delivers up to 4000+ charge cycles – 3–5x longer than traditional lead-acid batteries.
Fast opportunity charging – ready to recharge during breaks without performance loss
Up to 4000 cycles cuts replacement costs and long-term operating expenses
Stable voltage output throughout the discharge cycle for consistent performance until the end of each shift
10-year design life and 5-year warranty from the UFOPOWER factory
Low self-discharge, suitable for intermittent and multi-shift operation
Every UFOPOWER 24V pack is built with an integrated fireproof enclosure and a comprehensive multi-protection system, engineered for maximum safety in demanding industrial environments.
Built-in smart BMS: overcharge, over-discharge, temperature & short-circuit protection
IP67-rated steel case – complete water and dust ingress protection
100% fireproof construction with advanced thermal management
Optional GPS real-time tracking with remote lock/unlock for fleet management
Optional cloud-based diagnostics & OTA upgrades for remote monitoring and maintenance alerts
Operating temperature range -20°C to 65°C; optional heating function for charging at freezing temperatures
Around 70% lighter than lead-acid batteries, the 24V series is easy to install and handle, and requires no watering, no acid, and no ventilation – while our factory supports fully customized lithium solutions for your exact equipment.
Lightweight & compact – reduces operational strain, energy consumption, and tire/rim wear
Maintenance-free operation – no daily maintenance, saving labor and cost
Drop-in design – fits most 24V forklift battery compartments without modification
Custom OEM/ODM: voltage, capacity, dimensions, BMS communication protocols, and connectors tailored to your specs
Made in China by UFOPOWER – automated production lines with AI-driven quality control and final product inspection
Certified: ISO9001, CE, MSDS, UN38.3, IEC62619, RoHS, plus sea & air transport safety reports
