All models share a 51.2V nominal LiFePO4 system, integrated smart BMS (overcharge, over-discharge, temperature & short-circuit protection), and compatibility with most industrial 48V forklift chargers. The UFO48300 is available in two configurations: a standard high-rate version and a compact version for space-constrained battery compartments.
| Parameter | UFO48300 (Standard) | UFO48300 (Compact) | UFO48560F |
|---|---|---|---|
| Nominal Voltage | 51.2V | 51.2V | 51.2V |
| Rated Capacity | 300Ah | 300Ah | 560Ah |
| Energy | 15564.8Wh | 15564.8Wh | 28672Wh |
| Dimensions (L×W×H) | 975×780×625mm | 728×350×530mm | 905×812×479mm |
| Weight | ~135KG | 125KG | ~255KG |
| Charge Voltage | 58.4V | 58.4V | 58.4V |
| Cut-off Voltage | 40V | 40V | 40V |
| Charge Current | 200A | 50A | 200A |
| Continuous Discharge | 350A | 100A | 350A |
| Peak Discharge | 700A | 200A | 700A |
| Cycle Life | >4000 cycles | >4000 cycles | >4000 cycles |
| BMS | Built-in | Built-in | Built-in |
Note: The above are standard lineup examples. UFOPOWER offers extensive custom engineering – voltage & capacity from 24V to 80V+ (up to 1000Ah+), physical dimensions to fit your equipment, communication protocols compatible with most BMS systems, special features (low-temp heating, GPS tracking, remote monitoring), and customized connector types.
Engineered for the most demanding material handling equipment, the 48V series delivers high continuous and peak discharge currents for large-capacity lifting, acceleration, and continuous operation – with up to 4000+ charge cycles for long-term cost savings.
High-rate output: up to 350A continuous / 700A peak discharge on high-rate models
Up to 4000 cycles – 3–5x longer lifespan than traditional lead-acid batteries
Stable voltage output throughout the discharge cycle for consistent performance to the end of each shift
10-year design life and 5-year warranty from the UFOPOWER factory
Two 300Ah configurations (standard & compact) to fit different battery compartments
Every UFOPOWER 48V pack is built with an integrated fireproof enclosure and a comprehensive multi-protection system, engineered for maximum safety in demanding industrial environments.
Integrated smart BMS: overcharge, over-discharge, temperature & short-circuit protection
Steel case with IP67-rated water and dust ingress protection
100% fireproof construction with advanced thermal management
Optional GPS real-time tracking with remote lock/unlock for fleet management
Optional cloud-based diagnostics & OTA upgrades for remote monitoring and maintenance alerts
Operating temperature range -20°C to 65°C; optional heating function for charging at freezing temperatures
Around 70% lighter than lead-acid batteries, the 48V series is easy to install and handle, and requires no watering, no acid, and no ventilation – while our factory supports fully customized lithium solutions for your exact equipment.
Lightweight & compact – reduces operational strain, energy consumption, and tire/rim wear
Maintenance-free operation – no daily maintenance, saving labor and cost
Drop-in design – fits most 48V forklift battery compartments without modification
Custom OEM/ODM: voltage, capacity, dimensions, BMS communication protocols, and connectors tailored to your specs
Made in China by UFOPOWER – automated production lines with AI-driven quality control and final product inspection
Certified: ISO9001, CE, MSDS, UN38.3, IEC62619, RoHS, plus sea & air transport safety reports
